33. UPPER SLEWING STRUCTURE 33.1.3 BATTERY 33.1.3.1 REMOVING (1) Remove cover assy (1). 1. Loosen 4 sems bolts (22) M12X30. 2. Remove cover assy (1).
1 Removing cover assy (1) (2) Remove battery cover 1. Remove cable (A4) [between the earth and battery (-)]. (Always remove (-) terminal first and install it at last.) 2. Remove cable (A6) [between battery (+) and (-)] 3. Remove cable (A5) [between battery (+) and battery relay] Tools: Spanner: 13mm
A4
A6
A5
Removing and installing battery cable
(3) Remove battery (B1) 1. Remove rubber (A2). 2. Loosen 2 capscrews (A4) M10X200. Tools: Socket: 17mm 3. Remove plate (A1). 4. Remove battery (B1).
Follow the battery removal order. Start removing battery from grounding side, and finish attaching to grounding side. If this order is missed, shortcircuits may occur.
