33. UPPER SLEWING STRUCTURE 33.1.3 BATTERY 33.1.3.1 REMOVING (1) Open panel assy (1). 1. Unlock with starter switch key. 2. Open panel assy (1). 3. Keep panel assy open with stay.
1 Opening and closing of panel assy (1) (2) Remove battery cover 1. Remove cable (A4) [between the earth and battery (-)]. (Always remove (-) terminal first and install it at last.) 2. Remove cable (A2) [between battery (+) and (-)] 3. Remove cable (A3) [between battery (+) and battery relay] Tools: Spanner: 13mm (3) Remove battery (B1) 1. Loosen 2 capscrews (A2) M10X235. Tools: Socket: 17mm 2. Remove plate (A1). 3. Remove battery (B1).
A4
A3
A2
Removing and installing battery cable
Follow the battery removal order. Start removing battery from grounding side, and finish attaching to grounding side. If this order is missed, shortcircuits may occur.
33-8
