FIGURE 10 1. SPECIAL OPTIONS LIST

FIGURE 10-1. SPECIAL OPTIONS LIST

ITEM PART NUMBER QTY

DESCRIPTION

Ref MISCELLANEOUS SPECIAL OPTIONS: Ref Airline Installations - 1/2in 0270315 Ref Airline Installations E600 & M600 0270437 Ref Airline Installations E600J & M600J 0270447 Ref Airline Installations E600JP & M600JP 1001125782 Ref Battery Charger Replacement Kit (Replace MAC Charger with

Delta-Q Charger)

1001148971 Ref Bolt-on Lanyard Kit (Platform) Ref Boom Hose Kit Options: 1001198663 Ref Boom Hose Kit - E/M600 1001198662 Ref Boom Hose Kit - E/M600J 1001198661 Ref Boom Hose Kit - E/M600JP Ref Boom Wipers Installations 0270364 Ref Boom Wipers Installations E600 & M600 0270413 Ref Boom Wipers Installations E600J/JP & M600J/JP 0256789 Ref Camera Mounting Installation 0270374 Ref Cold Weather Package Installation (M600/J/JP Only) 1060626 1 Cord, Electrical - 3 Way 2580050 1 Heater, Immersion (Hydraulic Oil) (Prior to SN 0300208323) 1001188972 1 Heater, Immersion (Hydraulic Oil) (SN 0300208323 through

0300219271)

2580024 1 Heater, Battery 2580030 1 Heater, Pad 1702944 1 Decal - Heater Cord 1702941 1 Decal - Battery Heater 1702943 1 Decal - Hydraulic Tank Heater 1702942 1 Decal - Engine Block Heater 0258703 Ref Console Cover 0273172 Ref Container Shipment Preparation (Wheel Installation) Ref Cylinder Bellows Installations 0270014 Ref Fixed Axle (Prior to SN 0300201804) 1001188090 Ref Fixed Axle (SN 0300201804 through 0300219271) 0259995 Ref Oscillating Axle (Prior to SN 0300201804) 1001188320 Ref Oscillating Axle (SN 0300201804 through 0300219271) 0270340 Ref Cylinder Bellows Installations E600 & M600 0270314 Ref Cylinder Bellows Installations E600J/JP & M600J/JP Ref Decal Installations Options: 1702788 Ref Decal - Biodegradable Hydraulic Fluid (All except German Spec) 1703479 Ref Decal - Biodegradable Hydraulic Fluid (German Spec Only) 1704174 Ref Decal - Biodegradable (Synthetic) Hydraulic Fluid (All Specs except German Spec) 1704175 Ref Decal - Biodegradable (Synthetic) Hydraulic Fluid (German Spec Only) 1001196701 Ref Decal - Blueline Rentals 0274541 Ref Decal - Head and Enquist Equipment L.L.C (H & E) Installation 1001143072 Ref Decal - Hewitt Rentals Installation (English Spec) 1001143507 Ref Decal - Hewitt Rentals Installation (French Spec) 1702868 Ref Decal - No Hands (English) (Used with Platform Padding or Mesh to Top Rail on Side Entry Platforms)

REV

ITEM PART NUMBER QTY

DESCRIPTION

1001116846 Ref Decal - No Hands (English and Chinese) (Used with Platform Padding or Mesh to Top Rail on Side Entry Platforms) 1704000 Ref Decal - No Hands (English and French) (CSA Spec) (Used with Platform Padding or Mesh to Top Rail on Side Entry Platforms) 1703175 Ref Decal - Lanyard Attach (GM K-1 Spec) 0273371 Ref Decal - Nations Rents Installation 1001103341 Ref Decal - National Equipment Services (NES) Installation 0270687 Ref Decal - Sunbelt (Prior to SN 0300205726) 1001197878 Ref Decal - Sunbelt (SN 0300205726 through 0300219271) 1001151115 Ref Decal - Titan Rentals 0271894 Ref Decal - United Rentals 0270430 Ref Decal - U/L Tags (E600/E600J/E600JP Only) 1001141475 Ref Decal - Volvo Rents Installation 4420051 Ref Decal - Warning Stripes Ref Decal Kit Options: 2910866 Ref Decal - Kit - Platform (Prior to SN 0300139882) 1001119566 Ref Decal - Kit - Platform (SN 0300139882 through 0300219271) Ref Electrical Connector Kits 1001148902 Ref Amp Connector Kit 1001148903 Ref Deutsch DT Connector Kit 1001148904 Ref Deutsch HD Connector Kit 1001148905 Ref Packard Connector Kit 1001148906 Ref Various Connector Kit Ref Filter Kits: Ref Combined Filter Kit (Hydraulic/Air and Fuel/Engine Oil) 1001111002 1 Yanmar Engine (Prior to SN 0300088375) 1001111003 1 Kubota Engine (SN 0300088375 through 0300219271) Ref Hydraulic/Air Filter 1001109699 1 Yanmar Engine (Prior to SN 0300088375) 1001109701 1 Kubota Engine (SN 0300088375 through 0300219271) 1001110141 Ref Yanmar/Kubota Engine - Fuel/Engine Oil Filter 0272111 Ref "EE" Tight Fitting Enclosures (E600J/JP Models Only) 4060959 Ref Footswitch Shield (Note: Move Decal to Shield) 0272076 Ref Headlight and Taillight Installation (Prior to SN 0300196439) 1001175432 Ref Headlight and Taillight Installation (SN 0300196439 through

0300219271)

Ref Hydraulic Fluids Options: 2300016 Ref Mobil DTE 10 Excel 32 Ref Mobil DTE 10 Excel 15 Options: 2300028 Ref Bulk 70010346 Ref One Gallon Container 2300029 Ref Mobil EAL ISO 46 Bio 1001189164 Ref Low Temperature Cutout Installation Ref Platform Console Cover Options: 0258703 Ref Platform Console Cover (Prior to SN 0300200810)

See Note Ref Platform Console Cover (Note: Not Available) (SN 0300200810

through 0300202589)

1001195304 Ref Platform Console Cover (SN 0300202590 through 0300219271) 1001205175 Ref Platform Console Cover Add-on Kit 1001193754 Ref Platform Console/Ground Panel Illumination Light Installation 2915227 Ref Platform Conversion Kit (Changes Front Entry to Side Entry) Ref Platform Decal Panel Options: (ANSI Export Spec M600/J/JP

REV

ITEM PART NUMBER QTY DESCRIPTION

Only)

0270822 Ref Machines with Aluminum Console Box 0270823 Ref Machines with PVC Console Box Ref Platform Entry Kit 1001142504 Ref Kit, Replace Swing Gate with Drop Bar 1001142505 Ref Kit, Replace Drop Bar with Swing Gate 1001144020 Ref Kit, Side Entry, Drop Bar - 30in x 6ft (76cm x 1.83m) 1001144018 Ref Kit, Side Entry, Drop Bar - 30in x 4ft (76cm x 1.22m) Ref Platform Mesh Installations (Side Entry Platforms) 0273148 Ref 30in x 6ft (76cm x 1.83m) (To Top-Rail) 0273147 Ref 30in x 4ft (76cm x 1.22m) (To Top-Rail) 1001145985 Ref 30in x 6ft (76cm x 1.83m) (To Mid-Rail) 1001140318 Ref 30in x 4ft (76cm x 1.22m) (To Mid-Rail) Ref Platform Rail Extension Installations (Side Entry Platforms) 0274691 Ref 30in x 6ft (76cm x 1.83m) 1001103617 Ref 30in x 4ft (76cm x 1.22m) Ref SkyGuard Component Options: 1001143669 Ref SkyGuard Complete Add-on Kit 1001201620 Ref SkyGuard Complete Add-on Kit 1001137672 Ref SkyGuard Platform Sensor Kit 1001143256 Ref SkyGuard Blue Beacon Kit 1001176372 Ref SkyGuard Kit, Plug, Removal 1001149561 Ref SkyGuard Kit (With Beacon) 1001149563 Ref SkyGuard Kit (Without Beacon) Ref Strobe Light Installations (Amber) 1001152965 Ref Platform Mounted 1001154231 Ref Platform/Ground Mounted 1001199878 Ref Telematics Installation (Factory Installed) 1001200314 Ref Telematics Installation (Customer Supplied) 1001209282 Ref Telematics - Loxam 1001195610 Ref Telematics - United Rentals (Prior to SN 0300218567) 1001213869 Ref Telematics - United Rentals (SN 0300218567 through

0300219271)

Ref Tools for Service 7002828 1 Wire Stripper 7002821 1 Wire Crimper (To Install Wire Ends to Wires) 7002823 1 Pin/Socket Extractor - Universal (To Remove Pins/Sockets from Connectors) 4460467 1 Extractor - 16-18 Gauge (For Removal of Pins/Sockets for Deutsch Connectors) 4460510 1 Extractor - 12-14 Gauge (For Removal of Pins/Sockets for Deutsch Connectors) 7002840 1 Anti Pin Removal Tool - (Required to Disassemble Valve 4641143 to Install Seal Kit) 7002822 1 Screwdriver, Potentiometer (To Adjust Drive Controllers) 7016654 1 Screwdriver, Magnetic 7004275 1 Seal Installation Tool - 1in 7004276 1 Seal Installation Tool - 1-1/2in 7002826 1 Seal Installation Tool - 2in 2901443 1 Analyzer, Machine 1001137005 1 Software Cable Kit 1001200913 Ref Trickle Charger Installation

REV

ITEM PART NUMBER QTY DESCRIPTION

0257728 Ref Tube Rack Installation Ref Weld Leads Installations 0270363 Ref Weld Leads Installations E600 & M600 0270436 Ref Weld Leads Installations E600J & M600J 0270448 Ref Weld Leads Installations E600JP & M600JP

REV
