FIGURE 2-31. HOODS INSTALLATION
FIGURE 2-31. HOODS INSTALLATION
FIGURE 2-31. HOODS INSTALLATION
ITEM PART NUMBER QTY DESCRIPTION REV
Ref USAGE CHART: Machines SN 0300134874 through SN
0300134874 and Machines SN 1300006658 to Present Machines SN E300000001 through E300001114
Ref HOODS INSTALLATION Ref Caterpillar Engine Machines 1001105632 Ref USA Built Machines (SN 0300134874 through 0300145623) B 1001103771 Ref USA Built Machines (SN 0300145624 through 0300160834) B 0275866 Ref Belgium Built Machines (SN 1300006658 through
1300007162)
E 1001107280 Ref Belgium Built Machines (SN 1300007163 to Present) C 1001107280 Ref Romanian Built Machines (SN E300000001 through
E300001114)
C Ref Deutz Engine Machines 1001105632 Ref USA Built Machines D 1001091079 Ref Belgium Built Machines D 0275868 Ref GM Engine Machines D Ref Perkins Engine Machines 1001105632 Ref USA Built Machines D 0275866 Ref Belgium Built Machines E 1 0100011 AR Compound, Locking 2 0641408 AR Bolt 1/4in-20NC x 1-1/4in 3 0641606 3 Bolt 3/8in-16NC x 3/4in 4 0641608 13 Bolt 3/8in-16NC x 1in 5 0641610 2 Bolt 3/8in-16NC x 1-1/4in 6 0641614 4 Bolt 3/8in-16NC x 1-3/4in 7 0721004 4 Bolt #10-24NC x 1/2in 8 0721006 4 Bolt #10-24NC x 3/4in 9 0902504 1 Angle, Mounting 10 0940071 1 Bumper 11 0940083 2 Bumper 12 Ref Hood Kit (Engine Side) Options: 12 Ref USA Built Machines 12 2680438 1 Caterpillar Engine Machines (Includes Items 12A-12H, 23, 24 and Current Heat Shields) (Use p/n 1001101160) (Note: Item 32 must be ordered separately) (SN 0300134874
through 0300145623)
3 12 2680438 1 Caterpillar Engine Machines (Includes Items 12A-12K, 23, 24, 32 and Current Heat Shields) (Use p/n 1001091093) (SN
0300145624 through 0300160834)
5 12 2680438 1 Deutz Engine Machines (Includes Items 12A-12K, 23, 24, 32 and Current Heat Shields) (Use p/n 1001091093) 5 12 1671169 1 GM Engine Machines (Includes Items 12A-12H, 23, 24, 32 and Current Heat Shields) (Use p/n 1001091094) (SN
0300124000 through 0300140603)
3 12 1001117042 1 GM Engine Machines (Includes Items 12A-12H, 23, 24, 32 and Current Heat Shields) (SN 0300140604 through
0300160834)
A 12 2680438 1 Perkins Engine (Includes Items 12A-12H, 23, 24 and Current Heat Shields) (Use p/n 1001101160) (Note: Item 32 must be ordered separately) 3
12 Ref Belgium and Romanian Built Machines 12 2680438 1 Caterpillar/Perkins Engine (Includes Items 12A-12H, 23, 24 and Current Heat Shields) (Use p/n 1001101160) (Note: 3
ITEM PART NUMBER QTY
DESCRIPTION
Item 32 must be ordered separately) 12 2680438 1 Deutz Engine Machines (Includes items 12A-12K, 23, 24, 32 and Current Heat Shields) (USe p/n 1001091124) Ref Note: Replacement Decals Must be Ordered Separately -
See DECAL SECTION.
12A 2940109 1 Latch 12B 0721008 2 Screw, Machine #10-24NC x 1in 12C 4751000 4 Flatwasher #10 Regular 12D 3311005 2 Locknut #10-24NC 12E 2600210 1 Hinge 12F 3900232 4 Screw, Button Head 3/8in-16NC x 1-1/4in 12G 4751600 8 Flatwasher 3/8in Regular 12H 3311605 4 Locknut 3/8in-16NC 12J 2820099 3 Foam, Acoustical (Deutz Engine Machines Only) 12K 2820100 2 Foam, Acoustical (Deutz Engine Machines Only) 13 2680439 1 Hood Kit (Tank Side) (Includes Items 13A-13H, 23, 24 & 38) (Use p/n 1001091125) Ref Note: Replacement Decals Must be Ordered Separately -
See DECAL SECTION.
13A 2940109 1 Latch 13B 0721008 2 Screw, Machine #10-24NC x 1in 13C 4751000 4 Flatwasher #10 Regular 13D 3311005 2 Locknut #10-24NC 13E 2600246 2 Hinge 13F 0721006 4 Screw, Machine #10-24NC x 3/4in 13G 4751000 8 Flatwasher #10 Regular 13H 3311005 4 Locknut #10-24NC 14 3311401 2 Nut 1/4in-20NC 15 3311405 AR Locknut 1/4in-20NC 16 3311505 2 Nut 5/16in - 18NC 17 3311601 AR Nut 3/8in-16NC 18 3311605 10 Locknut 3/8in-16NC 19 Ref Panel, Rubber Options: 19 Ref Deutz/GM/Perkins Engine Machines 19 3380445 1 USA Built Machines (SN 0300134874 through 0300159527) 19 1001138444 1 USA Built Machines (SN 0300159528 through 0300160834) 19 3380445 1 Belgium Built Machines 19 3380445 1 Romanian Built Machines (SN E300000001 through
E300000493)
19 1001138444 1 Romanian Built Machines (SN E300000494 through
E300001114)
19 Ref Caterpillar Engine Machines 19 3380445 1 USA Built Machines (SN 0300134874 through 0300145623) 19 1001103791 1 USA Built Machines (SN 0300145624 through 0300160834) 19 3380445 1 Belgium Built Machines (SN 1300006658 through
1300007162)
19 No Required 0 Belgium Built Machines (SN 1300007163 to Present) 19 No Required 0 Romanian Built Machines (SN E300000001 to Present) 20 3573024 1 Plate, Hinge Mounting 21 3900232 3 Capscrew, Button Head 3/8in-16NC 1-1/4in 23 3960462 9 ft/2.74m Seal, Hood 24 3960464 9 ft/2.74m Seal, Hood 26 4160170 1 Spring, Gas
REV
3
1
ITEM PART NUMBER QTY DESCRIPTION
27 4740362 AR Washer, Fender 28 4750800 12 Flatwasher #8 Regular 29 4751400 AR Flatwasher 1/4in Regular 30 4751500 AR Flatwasher 5/16in Regular 31 4751600 40 Flatwasher 3/8in Regular 32 Ref Exhaust Tube Weldment Options: 32 4845194 1 Caterpillar/Deutz/Perkins Engine Machines 32 Ref GM Engine Machines 32 3460373 1 GM Engine Machines (SN 0300124000 through
0300140603)
32 1001117038 1 GM Engine Machines (SN 0300140604 through
0300160834)
33 4846037 1 Hood Mounting Weldment 34 Ref Hood Mounting Weldment Options: 34 4341390 1 Deutz/Perkins Engine 34 Ref Caterpillar Engine Options: 34 4341390 1 USA Built Machines (SN 0300134874 through 0300145623) 34 1001099364 1 USA Built Machines (SN 0300145624 through 0300160834) 34 4341390 1 Belgium Built Machines (SN 1300006658 through
1300007162)
34 1001099364 1 Belgium Built Machines (SN 1300007163 to Present) 34 1001099364 1 Romanian Built Machines (SN E300000001 through
E300001114)
34 4341389 1 GM Engine Machines 35 4846424 1 Hood Mounting Weldment 36 3311005 4 Locknut #10-24NC 37 4751000 8 Flatwasher #10 Regular 38 4060805 6 ft/1.75m Flex-Trim 39 1001105273 1 Insulation, Heat Shield (Used on Caterpillar/Deutz/Perkins Engine Machines) 39 1001105273 1 Insulation, Heat Shield (Used on GM Engine Machines) (Use p/n 1001117139) 40 1001105275 1 Insulation, Heat Shield (Used on Caterpillar/Deutz/Perkins Engine Machines) 40 1001105275 1 Insulation, Heat Shield (Used on GM Engine Machines) (Use p/n 1001117139) 41 4740500 3 Washer, Special (Not Used on Deutz Engine Machines) 42 1001105272 1 Insulation, Heat Shield (Used on Caterpillar/Deutz/Perkins Engine Machines) 42 1001105272 1 Insulation, Heat Shield (Used on GM Engine Machines) (Use p/n 1001117139) 43 1001105276 1 Insulation, Heat Shield (Used on Caterpillar/Deutz/Perkins Engine Machines) 43 1001105276 1 Insulation, Heat Shield (Used on GM Engine Machines) (Use p/n 1001117139) 44 1001109495 1 Insulation, Heat Shield (Used on Caterpillar/Deutz/Perkins Engine Machines) 45 1001117140 AR Tape, Aluminized Polyester (Used on GM Engine Machines)
