58 Maintenance Section Maintenance Recommendations
SEBU8311-02
Maintenance Recommendations
1. Stop the engine. 2. Wait for ten minutes. i03751181
System Pressure Release Coolant System
Do not loosen the high pressure fuel lines in order to remove air pressure from the fuel system.
Engine Oil To relieve pressure from the lubricating system, turn off the engine. i03751203
Pressurized system: Hot coolant can cause serious burn. To open cap, stop engine, wait until radiator is cool. Then loosen cap slowly to relieve the pressure. To relieve the pressure from the coolant system, turn off the engine. Allow the cooling system pressure cap to cool. Remove the cooling system pressure cap slowly in order to relieve pressure.
Fuel System To relieve the pressure from the fuel system, turn off the engine.
High Pressure Fuel Lines (If Equipped)
Contact with high pressure fuel may cause fluid penetration and burn hazards. High pressure fuel spray may cause a fire hazard. Failure to follow these inspection, maintenance and service instructions may cause personal injury or death. The high pressure fuel lines are the fuel lines that are between the high pressure fuel pump and the high pressure fuel manifold and the fuel lines that are between the fuel manifold and cylinder head. These fuel lines are different from fuel lines on other fuel systems. This is because of the following differences:
• The high pressure fuel lines are constantly charged
Welding on Engines with Electronic Controls NOTICE Because the strength of the frame may decrease, some manufacturers do not recommend welding onto a chassis frame or rail. Consult the OEM of the equipment or your Perkins dealer regarding welding on a chassis frame or rail. Correct welding procedures are necessary in order to avoid damage to the engine's ECM, sensors, and associated components. When possible, remove the component from the unit and then weld the component. If removal of the component is not possible, the following procedure must be followed when you weld on a unit that is equipped with a Perkins Electronic Engine. The following procedure is considered to be the safest procedure to weld on a component. This procedure should provide a minimum risk of damage to electronic components. NOTICE Do not ground the welder to electrical components such as the ECM or sensors. Improper grounding can cause damage to the drive train, the bearings, hydraulic components, electrical components, and other components. Do not ground the welder across the centerline of the package. Improper grounding could cause damage to the bearings, the crankshaft, the rotor shaft, and other components.
• The internal pressures of the high pressure fuel
Clamp the ground cable from the welder to the component that will be welded. Place the clamp as close as possible to the weld. This will help reduce the possibility of damage.
Before any service or repair is performed on the engine fuel lines, perform the following tasks:
Note: Perform the welding in areas that are free from explosive hazards.
with high pressure.
lines are higher than other types of fuel system.
