Engine
Engine Mechanical 8.1L 6-105
Notice: Refer to Fastener Notice in Cautions and Notices. 14. Install the engine coolant temperature (ECT) sensor into the right cylinder head. Tighten Tighten the ECT sensor to 20 N.m (15 lb ft). 15. Install the ECT sensor bracket and bolt. Tighten Tighten the ECT sensor bracket to 50 N.m (37 lb ft).
470744
16. Install the cylinder head coolant hole plug (1) into the left cylinder head. Tighten Tighten the cylinder head coolant hole plug to 23 N.m (17 lb ft).
635678
Oil Pump Disassemble Important: The oil pump pipe has a press fit into the oil pump. DO NOT remove the pipe from the oil pump. The pipe and oil pump are serviced as a complete assembly. 1. Remove the oil pump driveshaft and retainer.
427935
2001 Marine/Industrial
