MACHINE TRACTION !
WARNING
• To draw a machine, use a shackle and a wire rope, the strength of which are at least one and a half times as strong as the machine weight. The wire rope must be free from kinks, twists, and breaks. • While drawing a machine, make sure that no person comes between the tractor and the machine drawn. • Put the wire rope horizontally, while making it face the track frame straight. • Draw the traction rope gradually, taking care not to load it abruptly. • Move the target machine slowly. • Drawing a machine on a downward slope may let the machine run away out of control. On a bad upward slope, watch the wire carefully. Always use the traction hook in the back of the bottom frame of the machine drawn.
IMPORTANT Wire ropes which diameter are more than ø30 can be used. A shackle must be strong enough to draw the machine.
ø30 or more
How to releasing the brakes of the final drive • Remove the center gear from the final drive as following procedures. ③ • Order of removal; ① Snap ring →② Cover →③ O-ring →④ Slide ring • Pull the ⑤ center gear out, the brakes are released. ②
①
④
⑤
※ Reinstall the parts immediately after drawing the vehicle. ※ Be care of handling that the parts never catch dirt or contamination. - 41 -
