ANTI-VIBRATION SYSTEM
GB Anti-vibration system
!
WARNING! The fuel that is used in the chainsaw poses the following hazards: 1. The fluid and its fumes are poisonous. 2. Can cause skin irritation. 3. Is highly inflammable.
Dismantling 1. Remove the following components: • Chain and guide bar. See instruction book. • Cylinder cover. See instruction book. • Tank unit. See page 34. 2. Detach the springs from the cylinder with the help of a 4 mm Allen key. See fig. 1. 3. Detach the springs from the tank unit with service tools 502 52 18-01 and 502 52 18-02. See fig. 2.
Cleaning and inspection Clean and inspect all parts.
Fig. 1
Reassembly 1. Use pliers to attach the springs to the tank unit. 2. Attach the springs to the cylinder with the help of a 4 mm Allen key. See fig. 1. Tighten the bolts to 10 Nm. 3. Refit the following components: • Tank unit. See page 35. • Cylinder cover. See instruction book. • Chain and guide bar. See instruction book.
Fig. 2
36 – English
