CENTRIFUGAL CLUTCH
Centrifugal clutch A
Dismantling During dismantling of the centrifugal clutch, the chain brake must be in the off position. 1. Remove the cylinder cover, chain and guide bar. See instruction book. 2. Remove the chain guide-plate by removing the bolt (A). See fig. 1. 3. Remove the circlip (B) and washer and remove the clutch drum (C), together with the needle roller bearing (D) and chain drive-wheel (E). See fig. 2.
Fig. 1
4. Remove the spark plug, insert the piston stop tool and unscrew the clutch hub with the clutch tool. Note - lefthand thread. Turn in the direction of the arrow as shown in fig. 3. B The following points (5-7) describe the dismantling of the clutch hub.
E D C
5. Using a screwdriver, lever in the lip of the spring such that the spring sticks out a little on the other side. See fig. 4. NOTE! The clutch springs should not be opened out more than necessary. Risk of deformation.
Fig. 2
6. Stretch out the springs with circlip pliers and remove them from the clutch hub. 7. Remove the clutch shoes.
Fig. 3
Fig. 4 22 – English
