SAFETY EQUIPMENT
GB Chain brake Dismantling
B
1. First remove the following components: • Chain and guide bar. See instruction book. • Centrifugal clutch. See page 22.
A 2. Push the hand guard forward so that the chain brake is on. See fig. 1
3. Unscrew hand guard, two bolts. Note sleeving on the starter side. See fig. 2.
Fig. 1
4. Remove bolt (A) and chain guide-plate. See fig. 1. 5. Undo the four bolts (B) and remove the chain brake assembly cover. See fig. 1.
Fig. 2
!
WARNING! Check that the chain brake is in the on position. If it is not, the pressure spring can fly up causing personal injury.
D
C 6. Press down the retaining bush (C) and remove the lever arm (D). See fig 3. 7. Remove the pressure spring by freeing the rearward end with a screwdriver. See fig 4. 8. Remove the toggle joint (E) with attached brake-strap. See fig 4.
Fig. 3
9. Disconnect the brake-strap from the toggle joint. 10.Take out the retaining bush (C) and spring. See fig 3. E
Fig. 4 12 – English
