SECTION 5 TROUBLESHOOTING Group 3 Troubleshooting A Fault Code W: 2304 Fault Code W: 2304
Trouble Fuel Sensor Failure
Inspection Method Measure resistance between sensor #1 and #2.
Evaluation Cause The value is not within the Faulty sensor normal values. (Refer to the table.) 0V Open circuit in harness #2.
Measure voltage between sensor harness end #2 and the body. Measure resistance between ∞ Ω sensor harness end #1 and the body. The check mentioned above is normal.
Fuel Gauge B
No. A B C D E F
A
C D E
Fuel Level (%) 79 70 58 45 34 0 (EMPTY)
F TADB-05-02-024
Connector (Harness end) Fuel Sensor
TDCD-05-06-010
T5-3-4
Fuel Sensor (Ω) 18±1 26±1 33±1 44±2 59±2 840-4
Open circuit in harness #1.
Shorted circuit in harness #1 and #2.
