12/21 m (39/69 ft) swing-away lattice extension 3.2 Identification of the swing-away lattice extension
Serial number on section 1
Section 1 consists of a fixed section and an inclinable section.
On the inclinable section the serial number (1) is at the front on a plate to the right of the deflection sheave. The serial number (2) is at the rear left-hand side of the fixed section, on the lower plate.
Serial number on section 2
06.01.2006
On section 2 the serial number (1) is at the rear on the plate in the top chord.
3-8
3 112 239 en
Lattice extension operating instructions GMK 5220
