Homepage 8.7/15 m swing-away lattice extension 3.3 Identification of the swing-away lattice extension
3.3
Identification of the swing-away lattice extension The swing-away lattice extension is designed for the truck crane with which it was delivered. The sections of the swing-away latticeextension belonging to the truck crane have the same serial number as the truck crane. The following sections are identified by the serial number: – Section 1 (9 m) on the fixed section, – Section 1 (9 m) on the inclinable section,
S H
Risk of accidents during operation with non-modified swing-away lattice extension Only operate the truck crane with those sections of the swing-away lattice extension which have the same serial number as the crane. The SLI is set only for this swing-away lattice extension. This prevents malfunctions and damage. For technical reasons a truck crane may only be set with one swing-away lattice extension. If you wish to use the swing-away lattice extension on several GROVE truckcranes, the swing-away lattice extension sections must be adjusted for the corresponding cranes and labelled with all of the respective serial numbers. Risk of accidents if not adjusted correctly The swing-away lattice extension should only be adjusted by CraneCARE at the particular location.
s
16.07.2004
S
– Section 2 (6 m).
Operating instructions lattice extension GMK 3055/GMK 3050-1
2 084 894 en
3-7
