DECAL LOCATIONS GENERAL INFORMATION
Decal Locations information is provided to assist in the proper selection and application of new decals, in the event the original decal(s) become damaged or the machine is repainted. Refer to the listing for the illustra tion reference number, part number, description and quantity of each decal provided in the Kit. Refer to the appropriate illustration(s) for replacement location(s). To insure proper selection of the correct replacement decals, compare all of the various closeup location pho tographs to your machine, before starting to refinish the unit. Then, circle each pictured decal (on or otherwise applicable to your machine) while checking-off its par number in the listing. After you have verified all the decals needed for replacement, place the extra unneces sary decals aside for disposal. NEW DECAL APPLICATION
Surfaces MUST be free from dirt, dust, grease and other foreign material before applying the new Decal. To apply, remove the smaller portion of the decal backing paper and apply this part of the exposed adhesive backing to the clean surface while maintaining proper position and alignment. Peel the other portion of the backing paper off slowly while applying hand pressure to smooth out Decal surface.
A
CAUTION: Always Observe Safety Rules Shown on Decals. If Decals become dam aged, or If unit Is repainted, replace Decals. II repainting, BE SURE that all Decals from the Klt(s) which apply to your machine, are affixed to your unit. NOTICE Order paint for refinishing machines from this list: 901225 One Gallon Blaze Paint 901226 One Gallon Maize Paint 6 (12 oz.) Cans Blaze Spray Paint 610239 6 (12 oz.) Cans Maize Spray Paint 610240
6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34
065827 Decal - Shear Bolt 067493 Red Reflector Strip (2 places) 069151 Decal- Place this Edge Under Lip 069348 Decal - Reverse Overloads 071718 WARNING - Rotating Guard 072058 CAUTION - Close or Replace Guard (2 places) 072148 DANGER - Avoid Electrical Contact 072150 WARNING - Keep Hands Out (2 places) 072151 CAUTION - 1000 RPM Operation Only 072152 CATUION - 540 RPM Operation Only NOT Shown 072159 DANGER - Rotating Component 072900 Decal - Patent - NOT Shown 073085 Decal- 1000 RPM Only 073084 Decal - 540 RPM Only - NOT Shown 074487 Decal - Cutterbar Replacement 075566 Decal- Replace Only with GEHL Chain 075684 CAUTION - Implement Hltchpln 075806 Decal - Decorative GEHL 075807 Decal - Pointed Decorative GEHL 075808 Decal - Decorative Stripe 075809 Decal - Stripe Point 075810 Decal - Drawbar Clip Setup 076894 CAUTION - Operator's Responsibility & Manual 077682 CAUTION - General Safety Precautions 077214 Decal - Cutterbar Adjustment 077734 Decal - Maximum Tractor Horsepower 077814760 (Vertical) 077981 Decal - Use Grade 5 Shear Bolt Which Shears Thru Body & Double Nut 078110760 (Horizontal) 078212 Decal- Length-of-Cut Chart 078622 CAUTION - Towing Implements Without Brakes
The Decal Set Number for the HS783 Hydraulic Knife Sharpener is 075016. The Set includes the following: 35 36 37 38 39
057658 Decal - HOT Couplers 058392 Decal - Shutoff Valve - Not Used on CB760 065269 Decal- Knife Sharpening Instructions 072257 WARNING - Remove PTO Drive 072279 WARNING - Wear Safety Goggles
~30 1
The Decal Set Number for the CB760 is 078623. The Set includes the following: Ref. Part No. Number 1 .2 3 4 5
2
Description & Quantity
055948 Decal - Important Drive Replacement Notice 060150 Decal - NO Step (Electrically Controlled Deflector Models Only) 061684 Decal- Rotating Spiral Symbol 064355 Decal - FNR (ElectriC Shift Models Only) 065755 Decal - Belt Tightener Idler Instructions
