TROUBLESHOOTING Using troubleshooting chart If you are experiencing a problem that is not listed in this chart, see your Frontier dealer for service. When you have checked all the possible causes listed and you are still experiencing the problem, see your Frontier dealer.
IF EXCESSIVE TINE WEAR TILLER BUMPING ON GROUND
INSUFFICIENT DEPTH OBTAINED
TILLED SOIL TOO FINE TILLED SOIL TOO COARSE
CHECK Replace loose or bent tine. Replace tine when worn to a point. Obstacles entangled in tines. Blades incorrectly mounted with no tine spiral effect. Tines fitted with blunt edge leading. Broken tines. Adjust depth control skids. Insufficient power - use lower tractor speed. Chain cover on hard soil - further passes required. Blades rolling over ground - use lower tractor speed. Adjust depth control on tractor. Raise leveling board. Use a faster tractor ground speed. Lower leveling board. Use lower tractor speed. Wait until soil is drier.
TINES BALLING UP WITH SOIL
Raise leveling board. Decrease tractor speed. Ground too sticky for working. CUTTING TOO DEEP ON ONE SIDE Tiller not level:
NOT OVERLAPPING
• Level tiller. • Adjust depth control skid. Drive closer to last run. Start in center and go around clockwise. (Tilled soil to the right of the operator.)
Troubleshooting - Page 26
