TORQUE SPECIFICATION TABLE TORQUE SPECIFICATION TABLE FOR HYDRAULIC FITTINGS Use the following torques when a specific torque is not given. Note: These values apply to fittings when dry. These values do not apply if lubricants are used..
SIZE OF FITTINGS
TORQUE
SIZE ( JIC ) - INCHES 03 - 3/8"- 24 04 - 7/16"- 20 05 - 1/2"- 20 06 - 9/16"- 18 08 - 3/4"- 16 10 - 7/8"- 14 12 - 1 1/16"- 12 14 - 1 3/16"- 12 16 - 1 5/16"- 12 20 - 1 5/8"- 12 24 - 1 7/8"- 12 32 - 2 1/2"- 12
SIZE ( ORB ) - INCHES 03 - 3/8"- 24 04 - 7/16"- 20 05 - 1/2"- 20 06 - 9/16"- 18 08 - 3/4"- 16 10 - 7/8"- 14 12 - 1 1/16"- 12 14 - 1 3/16"- 12 16 - 1 5/16"- 12 20 - 1 5/8"- 12 24 - 1 7/8"- 12
OM 0401-A
38
foot-pounds
Newton-meters
8-9 13-15 14-15 23-24 40-43 43-48 68-75 83-90 112-123 146-161 154-170 218-240
12-13 18-20 19-21 32-33 55-57 59-64 93-101 113-122 152-166 198-218 209-230 296-325
foot-pounds
Newton-meters
8-10 14-16 18-20 24-26 50-60 72-80 125-135 160-180 200-220 210-280 270-360
11-13 20-22 24-27 33-35 68-78 98-110 170-183 215-245 270-300 285-380 370-490
