OPERATING INSTRUCTIONS (CONTINUED) THE CONTROLS FOR BG1000 ON/OFF CONTROL This toggle switch on top side of the grind motor is used to turn the grind motor on or off. ALWAYS WEAR PROPER SAFETY EYEWEAR AND RESPIRATOR EQUIPMENT WHEN OPERATING YOUR GRINDER. NEVER TURN ON YOUR GRINDER WITHOUT FIRST PUTTING ON THIS EQUIPMENT.
GRIND MOTOR ON/OFF SWITCH
FIG. 3 INFEED HANDWHEEL Turning the handle counterclockwise infeeds the grinding wheel, while turning the knob clockwise will move the grinding wheel away from the bedknife. THE MAXIMUM RECOMMENDED INFEED IS .003”. THIS IS APPROXIMATELY 1/24TH OF A TURN OF THE KNOB, OR A ROTATION OF 15 DEGREES.
FIG. 4
13
