ENGINE - K SERIES KV6 KV6 Engine – Camshaft Drive Belt Components
1 2 3 4 5 6 7 8 9 10 11 12
Bolt – timing gear to inlet camshaft (RH) Hub – camshaft front timing gear (RH) Camshaft front timing gear (RH) Drive belt (front) backplate cover – RH Engine mounting bracket Bolt – engine mounting bracket to front plate (4 off) Cover plate – drive belt Blanking plug Engine front plate Engine lifting bracket – front Cover – lower drive belt Drive belt (front) backplate cover – LH
12-3-10 DESCRIPTION AND OPERATION
13 14 15 16 17 18 19 20 21 22 23
Camshaft front timing gear (LH) Hub – camshaft front timing gear (LH) Idler pulley – drive belt Crankshaft timing gear Drive belt – front Front drive belt outer cover (LH) Screw – front drive belt outer cover to inner cover, LH (3 off) Front drive belt outer cover (RH) Screw – front drive belt outer cover to inner cover, RH (3 off) Tensioner assembly – front drive belt Bolt – timing gear to inlet camshaft (LH)
