ENGINE - K SERIES KV6 1 Strap – engine acoustic cover 2 Bolt – engine acoustic cover strap to manifold chamber 3 Engine acoustic cover 4 Bolt – manifold chamber to RH inlet manifold (4 off) 5 Manifold chamber 6 Screw – IAT/MAP sensor to manifold chamber (2 off) 7 IAT/MAP sensor 8 Seal – throttle body assembly to manifold chamber 9 Bolt – throttle body assembly to manifold chamber (4 off) 10 Throttle body assembly 11 'O' rings – inlet manifold to top cover, RH (3 off) 12 Inlet manifold, RH 13 Seal – manifold chamber to LH inlet manifold (3 off) 14 Guide block – HT lead 15 Stud – HT lead guide block/acoustic cover fixing 16 Inlet manifold, LH 17 Bolt – inlet manifold to cylinder head, LH (7 off) 18 Bolt – inlet manifold to cylinder head, RH 19 Gasket – inlet manifold to cylinder head, RH 20 Fuel rail 21 Gasket – inlet manifold to cylinder head, LH 22 Gasket – exhaust manifold to cylinder head, LH 23 Stud – exhaust manifold to cylinder head, LH (4 off) 24 Nut – exhaust manifold to cylinder head, LH (4 off) 25 Exhaust manifold, LH
DESCRIPTION AND OPERATION
12-3-9
