ENGINE - K SERIES KV6 1 Rear drive belt inner cover 2 Bolt – camshaft rear drive belt inner cover (4 off) 3 Camshaft gear – rear inlet 4 Drive belt – rear camshaft 5 Bolt – inlet camshaft gear 6 Bolt – camshaft rear drive belt outer cover (3 off) 7 Rear drive belt outer cover 8 Bolt – exhaust camshaft gear 9 Camshaft gear – rear exhaust 10 Seal – inlet camshaft, rear oil 11 Inlet camshaft 12 Seal – inlet camshaft, front oil 13 Stud – cylinder head to intake manifold (2 off) 14 Valve stem oil seal – inlet (6 off) 15 Valve spring – inlet (6 off) 16 Valve spring cap – inlet (6 off) 17 Collet – inlet valve (12 off) 18 Tappet – inlet valve (6 off) 19 Camshaft carrier 20 Bolt – cylinder head (8 off) 21 Bolt – camshaft carrier to cylinder head (22 off) 22 Seal – exhaust camshaft, rear oil 23 Exhaust camshaft 24 Tappet – exhaust valve (6 off) 25 Collet – exhaust valve (12 off) 26 Valve spring cap – exhaust (6 off) 27 Valve stem oil seal – exhaust (6 off) 28 Valve spring – exhaust (6 off) 29 Seal – exhaust camshaft, front oil 30 Bolt – camshaft cover (14 off) 31 Seal – oil filler cap 32 Oil filler cap 33 'O' ring – CMP sensor 34 CMP sensor 35 Bolt – CMP sensor 36 Spark plug (3 off) 37 Camshaft cover 38 Gasket – camshaft cover 39 Inlet valve (6 off) 40 Valve seat insert – inlet (6 off) 41 Valve guide – inlet (6 off) 42 Gasket – cylinder head 43 Exhaust valves (6 off) 44 Valve seat insert – exhaust (6 off) 45 Valve guides – exhaust (6 off) 46 Cylinder head
DESCRIPTION AND OPERATION
12-3-7
