ENGINE - K SERIES KV6 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27
'O' rings – oil filter housing to oil cooler pipes Oil pressure switch Screw – oil pump to cylinder block (16 off) Oil pump and oil filter housing assembly Gasket – oil pump housing Bearing ladder Crankshaft Dipstick Dipstick tube Baffle plate – lower crankcase extension Lower crankcase extension Screw – dipstick tube to cylinder block 'O' ring – oil pick-up pipe Oil pick-up pipe with integral strainer Screw – oil pick-up pipe to lower crankcase Connector (quick fit) – dipstick tube to sump Sump Bolt – sump to lower crankcase (10 off; 5 x short, 5 x long) Oil cooler Bolt – oil cooler to sump (3 off) Oil drain plug Seal – oil drain plug Pipe – oil cooler to oil filter housing Pipe – oil filter housing to oil cooler Oil filter cartridge Bolt (long) – bearing ladder to cylinder block (8 off) Bolt (short) – bearing ladder to cylinder block (8 off)
DESCRIPTION AND OPERATION
12-3-5
