ENGINE - K SERIES KV6 KV6 Engine – Cylinder Block Components
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
Clip – coolant pump to thermostat pipe 'O' ring – coolant pump to thermostat pipe Pipe – coolant pump to thermostat 'O' ring – coolant pump to thermostat pipe Clip – coolant pump to thermostat pipe Thermostat housing 'O' ring – coolant outlet elbow to cylinder block Bolt – coolant outlet elbow to cylinder block Coolant outlet elbow 'O' ring – thermostat housing to cylinder block Blanking plate – coolant outlet Seal – blanking plate Screw – blanking plate (2 off) Bolt – engine lifting bracket, rear (2 off) Engine lifting bracket – rear Screw – crankshaft rear oil seal (5 off) 2nd compression ring
18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
Top compression ring Oil control ring Piston Big-end upper bearing shell Big-end bearing cap Bolt – big-end bearing cap to connecting rod (2 off per piston) Big-end lower bearing shell Crankshaft rear oil seal Cylinder liner (6 off) Dowel – cylinder block to cylinder head (4 off) Cylinder block Dowel – cylinder block to lower crankcase (4 off) Engine coolant pump Screw – coolant pump to cylinder block (7 off) Seal – coolant pump to cylinder block
