ENGINE - K SERIES 1.8 1 Bolts – spark plug cover to camshaft cover (3 off) 2 Spark plug cover 3 Bolts – camshaft cover to camshaft carrier (15 off) 4 Oil filler cap 5 Oil filler cap seal 6 Bolt – camshaft sensor to camshaft cover 7 Camshaft sensor 8 'O' ring – camshaft sensor 9 Gasket – camshaft cover to camshaft carrier 10 Inlet air temperature (IAT) sensor 11 Nuts – inlet manifold to cylinder head studs (3 off) 12 Copper washer – IAT sensor to inlet manifold 13 Studs – inlet manifold to cylinder head (3 off) 14 Gasket – inlet manifold to cylinder head 15 Inlet manifold 16 Bolts – inlet manifold to cylinder head (4 off) 17 Spring clip – vacuum regulator to inlet manifold pipe 18 Pipe – vacuum regulator to inlet manifold 19 Cap screws – Manifold Absolute Pressure (MAP) sensor to inlet manifold (2 off) 20 Manifold Absolute Pressure (MAP) sensor 21 Camshaft cover assembly 22 Spring clip – breather hose to camshaft cover 23 Hose – camshaft cover to inlet manifold breather 24 Spring clip – breather hose to camshaft cover 25 Hose – camshaft cover to throttle body breather 26 Spring clip – breather hose to throttle body
