Maintenance procedures
1•5
Rear underbody view - Saloon and Hatchback models
1
1 Silencers (Section 21) 2 Rear brakes (Section 23) 3 Exhaust system rubber mounting (Section 21) 4 Handbrake cables (Section 23) 5 Suspension struts and springs (Section 19) 6 Fuel tank filler neck (Section 22) 7 Fuel filter (Section 33)
Rear underbody view - Estate models 1 Silencers (Section 21) 2 Rear brakes (Section 23) 3 Exhaust system rubber mounting (Section 21) 4 Handbrake cables (Section 23) 5 Suspension springs (Section 19) 6 Suspension shock absorbers (Section 19) 7 Fuel tank filler neck (Section 22) 8 Evaporative emissions control system charcoal canister (Chapter 6)
