1•4
Maintenance procedures Engine compartment components 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
Front underbody view 1 Radiator bottom hose (Section 12) 2 Exhaust gas oxygen sensor (Chapter 6) 3 Braking system, fuel and emission control system lines (Section 22) 4 Front disc brake (Section 23) 5 Manual transmission drain plug (Chapter 7, Part A) 6 Front suspension subframe (Chapter 2, Part B) 7 Manual transmission filler/level plug (Section 16) 8 Radiator undershield (Section 28) 9 Catalytic converter (Section 21) 10 Exhaust system rubber mountings (Section 21) 11 Engine oil drain plug (Section 15) 12 Engine oil filter (Section 15)
Spark plugs (Section 31) Engine oil filler cap (Section 3) Brake fluid reservoir (Section 3) Auxiliary fusebox (Chapter 12) Air cleaner assembly (Section 29) Battery (Section 9) Cooling system expansion tank (Section 28) Ventilation system pollen filter - under cowl grille panel (Section 27) Air intake resonator (Chapter 4) Radiator top hose (Section 12) Cooling system expansion tank filler cap (Section 3) Air intake plenum chamber (Chapter 4) Engine oil dipstick (Section 3) Vehicle Identification Number (VIN) plate Windscreen/tailgate washer fluid reservoir (Section 3) Auxiliary drivebelt (Section 11) Power steering fluid reservoir (Section 5)
