Hard Disk Drive Item
Specification
Drive Format Capacity (MB)
3240
3240
4320
Bytes per sector
512
512
512
Logical heads
16
16
15
Logical sectors
63
63
63
Logical cylinders
6282
6304
8944
Physical read/write heads
3
5
4
Disks
6
3
2
Spindle speed (RPM)
4000
4000
4200
128KB
512KB
512KB
Drive Format
Performance Specifications Buffer size Interface
IDE(ATA-3)
IDE
IDE(ATA-4)
Data transfer rete (diskbuffer, Mbytes/s)
6.0~9.1
6.4~10.4
7.7~12.8
Data transfer, rate (host~buffer, Mbytes/s)
16.6 (PIO mode 4)
16.6 (PIO mode 4) 33.3 (Ultra DMA mode 2)
5+-5%
5+-5%
DC Power Requirements Voltage tolerance
5+-5%
CD-ROM Item Vendor & Model Name
Specification TEAC CD-220EA-25/BE
Performance Specification Transfer rate (KB/sec)
1,290KB/sec ~ 3,000KB/sec. (FULL - CAV)
Access time (typ.)
180 mS
Rotation speed
4280 rpm (typ.)
Buffer memory
128 KB
Interface
ATAPI
Applicable disc format
CD-DA, CD-ROM (Mode-1, Mode-2), CD-ROM XA MODE-2 (FORM-1, FORM-2), Multi-Session Photo CD, CD-I, Video CD, Enhanced CD & CD PLUS Compatible
Loading mechanism
Drawer with soft eject and emergency eject hole
Power Requirement
