SPECIFICATIONS
SPECIFICATIONS 75, 90 Models Displacement
79.1 cu. in. (1296 cc)
Engine Type
In-line, 3 Cylinder, Two-Cycle, E-TEC
Full Throttle Operating Range
75 HP – 4500 to 5500 RPM 90 HP – 4500 to 5500 RPM
Power(1)
75 HP – 75 HP (56 kw) @ 5000 RPM 90 HP – 90 HP (67.1 kw) @ 5000 RPM
Idle RPM in Gear(2) Idle RPM in
Neutral(2)
700 ± 50 600 ± 50
Ignition Timing(2)
Not Adjustable
Emission Control System: per SAE J1930(2)
ECM, E-TEC (Engine Control Module, E-TEC)
Fuel Requirements(2)
87 Pump Posted AKI (90 RON) – Refer to Oil and Fuel on page 15
Oil – Lubricant
TC-W3 NMMA-certified oil or Evinrude/Johnson XD100 oil – Refer to Oil and Fuel on page 15 2.65 qt. (2.5 l)
– Capacity Warning Signals
Controlled by the outboard’s EMM
Battery, Minimum
640 CCA (785 MCA) 12 volt
Spark Plug(2)
Refer to ECI Label
Fuses
Refer to Fuse on page 29
Fuel Filter
In-line Replaceable
Battery Charging
25-Amp, Fully Regulated
Gearcase – Lubricant – Capacity
Evinrude Ultra-HPF™ L Models – 26 fl. oz. (770 ml) X Models – 42 fl. oz. (1250 ml)
Power Trim/Tilt – Fluid Capacity
21 fl. oz. (622 ml)
Propeller
Refer to Propeller Selection on page 40
Weight
L Models – 320 lbs. (145 kg) X Models – 335 lbs. (152 kg)
Sound at Driver’s Ear (LpA) ICOMIA 39.94
76.8 dB(A)
Transom Height
L Models – 19 1/2 to 20 in. (495 to 508 mm) X Models – 24 1/2 to 25 in. (622 to 635 mm)
(1) Rated following the standards of ICOMIA 28.83, ISO 3046 and NMMA. (2) Emission Control Information.
