TAP LOCATION Tap Number TP1
Description Hydraulic Oil Sampling (SOS)
Schematic Location D13
TP2
LH Propel Case Pressure
G13
TP3
RH Propel Case Pressure
G10
TP4
LH Propel Charge Pressure
H14
TP5
RH Propel Charge Pressure
H11
TP6
Left Propel Forward Pressure
I13
TP7
Left Propel Reverse Pressure
I13
TP8
Right Propel Forward Pressure
I10
TP9
Right Propel Reverse Pressure
I11
TP10
LH Conveyor Forward Pressure
J8
TP11
LH Conveyor Reverse Pressure
I8
TP12
LH Auger Reverse Pressure
I5
TP13
LH Auger Forward Pressure
J5
TP14
LH Feeder Charge Pressure
I6
TP15
RH Auger Reverse Pressure
I4
TP16
RH Auger Forward Pressure
J4
TP17
RH Conveyor Forward Pressure
J1
TP18 TP19 TP20 TP21 TP22 TP23 TP24 TP25 TP26 TP27 TP28 TP29 TP30 TP31
RH Conveyor Reverse Pressure RH Feeder Charge Pressure Generator Oil Sampling (SOS) Auxilliary Pump Pressure Auxilliary Pump Case Pressure Manual Brake Pressure Brake / Shift Pressure LH Track Tension Cylinder Pressure RH Track Tension Cylinder Pressure Tamper Pump Pressure Tamper Pump Case Pressure Feeder Charge Filter Oil Sampling (SOS) Feeder Charge Filter Pressure Truck Hitch Pressure
I1 I13 B8 E6 F10 E8 D7 E10 D10 B6 A5 B11 A11 D3
