Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes the USB diskette drives, the onboard hard disk drive and the DVD drive in the module bay. Select Boot Devices to select specific devices to support boot.
Information
Main
PhoenixBIOS Setup Utility Security Boot Exit Item Specific Help
Boot priority order: 1: IDE 0: HTS545016B9A300 2: IDE 1: 3: IDE 2: 4: USB FDD: 5: Network Boot: 6: USB HDD: 7: USB CD/DVD ROM:
F1 Help Es c Exit
Chapter 2
Select Item Select Menu
Use < > or < > to select a device, then press <F6> to move it up the List, or <F5> to move it down the list. Press <Esc> to escape the menu.
F5/F6 Enter
C h a n g e Va l u e s Select Sub-Menu
F9 F10
Setup Defaults Save and Exit
27
