Maintenance – Preparations/concluding work 8.2.1.2
Closing the protection hood To fasten the protection hood, use only the prescribed original screws. Always screw in and tighten all screws and their washers. Protective equipment: n Working clothes n Protective gloves
1
1.
Loosen the screw (1) on both sides.
2.
Close the protection hood.
3.
Tighten the screw (1) on both sides.
4.
Screw in screws (2) and washers on both sides and tighten them.
B-692-0204
Fig. 66
1
2
B-692-0205
Fig. 67
72
DRP45DX
