Maintenance – List of fuels and lubricants 8.3 List of fuels and lubricants Assembly group
Fuel or lubricant Summer
Engine oil
Filling quantity Winter
Observe the level mark!
SAE 10W-40
0.9 l
Specification: Ä Chapter 8.2.1 ‘Engine oil’ on page 69
(0.24 gal us)
SAE 15W-40 SAE 10W-30
Fuel
Exciter shaft housing
SAE 30
SAE 10W
Diesel
Winter diesel fuel
3.0 l
Specification: Ä Chapter 8.2.2 ‘Fuel’ on page 69
(0.8 gal us)
SAE 10W-40
0.4 l
Specification: Ä Chapter 8.2.3 ‘Oil for exciter shaft housing’ on page 70
(0.11 gal us)
Components may get damaged! Do not use low-ash engine oils for the exciter shaft housing. SAE 15W-40 SAE 10W-30 Steering rod
Hydraulic oil (ISO), HV 32
0.4 l
Specification: Ä Chapter 8.2.4 ‘Hydraulic oil’ on page 70
(0.11 gal us)
or ester based biodegradable hydraulic oil Specification: Ä Chapter 8.2.4.2 ‘Bio-degradable hydraulic oil’ on page 71 Water tank
Water
12.0 l (3.2 gal us)
72
DRP15D
