Operation – Work mode 4. CAUTION! Danger of injury caused by the crushing of body parts! – When reversing, steer the machine from the side using the steering handle. Pull the handle back. ð The machines vibrates backwards with a speed which corresponds with the handle position.
B-695-0006
Fig. 46 5.
Move the handle back to position “0”. ð The machine stops and vibrates on the spot.
B-695-0004
Fig. 47 6.
For short work interruptions you should always return the throttle lever to “MIN” position (idle speed). ð Vibration is switched off.
7.
For short work interruptions you should always park the machine in secured condition Ä Chapter 6.5 ‘Parking the machine in secured condition’ on page 60.
1.
Keep shifting the throttle lever between “MIN” and “MAX” positions.
B-695-0060
Fig. 48 Help if the machine gets stuck
At the same time use the steering rod to pull the machine right and left, until it comes free.
B-695-0061
Fig. 49
58
DRP15D
