Loading/transporting the machine – Loading the machine 7.1 Loading the machine Loads must only be attached and hoisted by an expert / qualified person. Do not use damaged or in any other way impaired lifting points. Use only lifting and lashing tackle with sufficient load bearing capacity for the weight to be loaded. Minimum load bearing capacity of lifting tackle: see operating weight Ä Chapter 2 ‘Technical data’ on page 11. Always use appropriate lifting and lashing tackle on the lifting and lashing points. Use lifting tackle only in the prescribed direction of load application. Lifting tackle must not be damaged by machine components. When lifting the machine, avoid uncontrolled movements of the load. If necessary, hold the load with guide ropes. Protective equipment: n Working clothes n Protective gloves 1.
Park the machine in secured condition Ä Chapter 6.5 ‘Parking the machine in secured condition’ on page 61.
2.
Allow the engine to cool down.
3.
Fold the guide handle forwards.
4.
Attach the lifting tackle to the designated lifting eye (1).
5. DANGER! Danger to life caused by suspended loads! – Do not step or stand under suspended loads. Lift the machine carefully and lower it again at the intended location. Fig. 52 6.
If necessary, pull the machine by the handles on an even surface.
Fig. 53
