1. GENERAL SPECIFICATION ITEMS
UNIT
STD.
OPT. 1
OPT. 2
OPT. 3
OPT. 4
OPT. 5
OPT. 6
OPERATING WEIGHT
ton
30.0
←
←
31.6
30.6
←
←
BUCKET CAPACITY (SAE)
m
3
1.27
1.51
1.03
0.64
1.27
1.51
1.03
ENGINE
RATED POWER
HP/rp
213/1,800
MAX. TORQUE
kg.m/rp
96/1,300
SYSTEM PRESSURE
2
kg/cm
350 (370) / 350
SWING SPEED
rpm
9.9
TRAVEL SPEED (High/Low)
km/h
5.3/3.0
%(deg
70 (35°)
GRADEABILITY SHOE WIDTH
mm
600
←
←
800
600
←
←
kg/cm2
0.57
←
←
0.45
0.58
←
←
BUCKET (Nor./Press. Up)
ton
18.9/ 20.0
←
←
10.0/ 10.5
16.9/ 18.0
←
←
ARM (Nor./Press. Up)
ton
13.2/ 13.9
16.0/ 17.0
11.7/ 12.4
7.1/ 7.5
13.2/ 13.9
16.0/ 17.0
11.7/ 12.4
MAX. DIGGING REACH
mm
10725
10155
11240
17510
10860
10280
11415
MAX. DIGGING DEPTH
mm
7305
6700
7950
13780
7010
6510
7605
MAX. DIGGING HEIGHT
mm
10325
10010
10405
14195
12085
11615
12450
REAR SWING RADIUS
Mm
3200
←
←
←
←
←
←
MIN. SWING RADIUS
mm
4040
4045
4050
6120
2820
3015
3015
OVERALL LENGTH
mm
10540
10720
10650
14290
10630
10760
10650
OVERALL WIDTH (STD.)
Mm
3200
←
←
3400
3200
←
←
OVERALL HEIGHT
mm
3370
3495
3575
3475
3465
3455
3700
GROUND CLEARANCE
mm
500
←
←
505
500
←
←
TRACK LENGTH
mm
4940
←
←
←
←
←
←
mm
2600
←
←
←
2400
←
←
GROUND PRESSURE DIGG -ING FORCE (ISO)
WORK -ING RANGE
TRANS POR TATION DIMEN SION
TRACK GAUGE (STD.)
OPTION ATTACHMENT
• BOOM : STD. 6,245mm, SLR 10,000mm, ARTI 6,260mm • ARM : STD. 3,100mm, SHORT1 2,500mm, SHORT2 2,850mm, LONG 3,750mm SLR. 7,000mm 3 • BUCKET (PCSA) : STD. 1.27 m 3 3 3 3 3 OPT. 0.80 m , 1.03 m , 1.51 m , 1.75 m , 0.64 m (for SLR.) • SHOE : STD. 600mm(G) OPT. 700mm(G), 800mm(G), 850mm(G), 600mm(DG) • COUNTER WEIGHT : STD. 5,300kg, OPT. 5,900kg (for Arti.), OPT. 6,300kg (for SLR.) 3
• STANDARD : STD. BOOM(6245mm), STD. ARM(3100mm), STD. BUCKET(1.27 m ) 3 • OPTION 1 : STD. BOOM(6245mm), SHORT ARM(2500mm), OPT. BUCKET(1.51 m ) 3 • OPTION 2 : STD. BOOM(6245mm), LONG ARM(3750mm), OPT. BUCKET(1.03 m ) • OPTION 3 : SLR. BOOM(10000mm), SLR. ARM(7000mm), OPT. BUCKET(0.64 m3), 800MM SHOE 3 • OPTION 4 : ARTI. BOOM(3.25mm LB + 3.05mm UB), STD. ARM(3100mm), STD. BUCKET(1.27 m ) 3 • OPTION 5 : ARTI. BOOM(3.25mm LB + 3.05mm UB), SHORT ARM(2500mm), OPT. BUCKET(1.51 m ) 3 • OPTION 6 : ARTI. BOOM(3.25mm LB + 3.05mm UB), LONG ARM(3750mm), OPT. BUCKET(1.03 m )
MODEL
DX300LC-3
DWG No
950103-00379
2/87
