BRAKING SYSTEM
DESCRIPTION
2. BRAKING SYSTEM DESCRIPTION The braking system is comprised of 2 braking devices (one for each rear wheel) operated by two hydraulic pumps by way of mechanical controls. Each pump supplies fluid to the brake on one side (left or right) thereby allowing the operator to brake on one side only and thus reduce the steering radius.
1 3 2 5 4
6
8 7
D0011720
1. 2. 3. 4.
Brake fluid reservoir Right master cylinder Brake microswitches (n° 2) Brake pedal
5. 6 7. 8
Rear axle Right brake Left brake Left master cylinder
