REAR PTO
DESCRIPTION
1.3 REAR PTO DESCRIPTION The rear PTO provides drive for external implements at a preselected rotation speed. The rotary drive is taken directly from the engine and then reduced through a 2 -or 4-speed gearbox with manual speed selection. The PTO is engaged by way of an electro-hydraulically controlled clutch. 2 SPEED VERSION
4 SPEED VERSION
1
1
2
3
3 5
4
5
4
6 7
1000 rpm 540 rpm
a b
750 rpm 540 rpm
a b
c 1400 rpm d 1000 rpm D0012700
1. 2. 3. 4. 5.
Clutch Synchronizer 540 rpm driven gear 1000 rpm driven gear PTO shaft
1. 2. 3. 4. 5. 6. 7.
Clutch Synchronizer 540 rpm driven gear 750 rpm driven gear PTO shaft 1000 rpm driven shaft 1400 rpm driven gear
10-17
