2A — INSTALLATION & WIRING: 1207A Controller
Although not usually necessary, a thermal joint compound can be used to improve heat conduction from the case to the mounting surface.
CONNECTIONS: Low Current An integrated 16-pin low power connector molded into the front of the controller provides the low power logic control connections (see pin list below). The mating connector is Molex Mini-Fit Jr., part number (5557) 39-01-2165. Contact Molex regarding compatible pins for various wire sizes.
Curtis PMC 1207/1207A Manual
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
Pin Pin Pin Pin Pin Pin Pin Pin
1 2 3 4 5 6 7 8
shunt field driver output; n/c for series motors reverse contactor driver output forward contactor driver output main contactor driver output throttle: 3-wire pot high throttle: 3-wire pot wiper or 0–5V throttle: pot low throttle: 2-wire 5kΩ–0 or 0–5kΩ input
Pin Pin Pin Pin Pin Pin Pin Pin
9 10 11 12 13 14 15 16
n/c emergency reverse (BB) check output [optional] reverse input forward input emergency reverse input mode selection input brake input keyswitch input (KSI)
20
