5 - ASSEMBLY
6. Insert the straight connector (A) than the 90° elbow (B) on each side of the valve block. Turn the elbow to face toward the rear of the machine.
RAPH12WEL1281BA
6
RAPH12WEL1281BA
7
7. Attach the right pilot spool hose (P) with the yellow and white ties, to the 90° elbow on the right side of the valve block. 8. Attach the left pilot spool hose (Q) with the red and white ties, to the 90° elbow on the left side of the valve block.
