4 - ASSEMBLY
20. Connect hose (18) to the rigid return-to-tank tube (14).
RAIL17TLB0579BA
13
RAIL17TLB0580BA
14
RAIL17TLB0570BA
15
21. Connect the hose (10) to the hammer valve “T” port straight fitting (6).
22. Connect the X-810 connector of the harness (20) to the solenoid (S) of the hammer control valve (1).
10 EN
