2 - KIT CONTENT Kit overview NOTICE: to check the items part numbers of this kit, please refer to the Parts Catalogue. NOTICE: refer to the standard torque table when threaded on this kit installation. The special torque values required are always provided in this installation instructions. NOTE: when referring to the instructions for call out references, the numeric [example: (1)] refers to item (1) in the kit contents bill of materials. The letter [example: (A)] refers to the component on the unit, not a component in the kit contents bill of materials. Please read the complete instructions before starting assembly. References to right-hand, left-hand, front, and rear are determined by seeing from the operator’s seat. NOTE: the following table shows the items numbered as in the installation instruction. Item 1 (*) 1 (**) 1 (***) 2 3 4 5 6 7
Description ECU, Telematics unit PCM, HIBT1, 4G NA, VZ ECU, Telematics unit PCM, HIBT1, 4G NA, VF ECU, Telematics unit PCM, HIBT1, 4G EMEA, VF Telematics antenna Tie cable, 6.7X.18 inch Nylon black Bolt, M6x30 mm Grommet, M22X30X38 Label, Telematics activation code Strap, fir tree
Quantity 1 1 1 1 3 3 1 1 3
NOTE: (*) ECU Telematics unit kit reference p/n 51583777 NOTE: (**) ECU Telematics unit kit reference p/n 55666160 NOTE: (***) ECU Telematics unit kit reference p/n 90331337
