3 - PRE-ASSEMBLY
4. Wait 5 seconds and turn the key to the ON position. Move all of the control levers in both directions several times to relieve the pressure in the lines. Turn the key to the OFF position. 5. Make sure that the brake accumulators are completely discharged. Push down and release the brake at least 30 times. 6. Move the safety lock link into the locked position to prevent articulation. Insert the safety security pin.
RCPH10WHL063BAL
3
RCPH11WHL653BAU
4
RCPH10WHL137AAH
5
7. Open the engine access hood. Turn the timed disconnect switch to the OFF position. NOTE: Wait 90 seconds after the engine shutdown before turning off the battery disconnect. After the engine shutdown, the Selective Catalytic Reduction (SCR) system does a purge and the supply module continues to run.
8. Loosen the fill cap in the hydraulic reservoir to relieve the pressure in the hydraulic reservoir and the system.
8 EN
