5 - ASSEMBLY

10. Install the JSS load sense hose (23) to the straight connector (5).

11. Install the JSS suction valve hose (26) to the 90° elbow (7).

12. Install the hose (27) to the 90° elbow (6).

13. Install the joystick steering tube (49) to the 90° long elbow (48).

14. Install the hose (15) to the 45° elbow (14).

15. Install the hose (16) to the 45° elbow (14).

LEIL20WHL1539GB

4

14 EN
