5 - ASSEMBLY
27. Install the LS steering hose (47) and the steering supply hose (46) on the orbitrol valve (P). 28. Install the two tees (9) on existing union tees (G) and (L). 29. Install the cylinder hydraulic hose (42) to the tee (9) (side base line). 30. Install the cylinder hydraulic hose (43) to the tee (9) (right side rod line). 31. Install the right steering cylinder tube (20) on the 90° elbow (E) of the steering cylinder (Q). 32. Install the o-ring (23) to the right steering cylinder tube (20). 33. Install the right side base hose (22) to the tee (9) and to the right steering cylinder tube (20). Secure with the hose clamp (26) and the clamp block (21). 34. Install the right side rod hose (14) to the tee (9) and the right-hand side tube (M).
18 EN
