5 - ASSEMBLY
19. Install the tee (10) to the suction valve hose (45). 20. Install the 45° elbow (18) to the LS steering hose (18). 21. Install the check valve (25) to the tee (10) and the to CF port of the steering priority valve (Z). 22. Install the steering supply hose (46) to the tee (10). 23. Install the straight connector (17) to the steering priority valve (Z). 24. Install the shuttle tee hydraulic valve (6) to the straight connector (17) and the 45° elbow (18). 25. Install the LS steering hose (47) to the shuttle tee hydraulic valve (6).
LEIL19WHL0696GB
8
16 EN
