CNH Joystick Steering Kit with Standard Hydraulic Steering 821G W190D Wheel Loader Installation Inst

Page 13

5 - ASSEMBLY

7. Install the o-rings (38A) supplied with the JSS cut-off valve (38) on the CL and the CR ports of the steering EHPS valve (3). 8. Install the JSS cut-off valve (38) on the steering EHPS valve (3). Secure with the six bolts M10x105 (40) and the six washers 11x21x2.5 (39). 9. Install the 45° elbows (41) on the C1 and the C2 ports of the JSS cut-off valve (38).

LEIL19WHL0684FB

3

13 EN
