4 - ASSEMBLY
4 - ASSEMBLY HYDRAULIC SYSTEM FOR 4X1 BUCKET
Installation of hydraulic system for 4X1 bucket Mandatory Declaration of Conformity updates NOTE: The hydraulic fluid will be released during this procedure, be prepared to direct the fluid into the suitable container and dispose of properly. NOTICE: Avoid the contamination, clean all the connections before disconnecting the tubes, the hoses, or the connectors. Cap or plug all the ports after disconnecting. ATTENTION: The dealer or the person who guarantees for the correct installation of the “4X1 bucket hydraulic system” must certify the correct assembly to the Manufacturer, in order to ask for the update of the EC Declaration of Conformity. 1. Refer to the service manual and remove/lift the cab if necessary. 2. Identify and disconnect the hoses (B1) from the two section loader control valve (A). 3. Identify and disconnect the hoses (B2) from the two section loader control valve (A). 4. Identify and disconnect the hose (B3) from the two section loader control valve (A). 5. Identify and disconnect the hoses (B4) from the two section loader control valve (A). RAIL16TLB1417AA
1
RAIL16TLB1417AA
2
RAIL16TLB1419AA
3
6. Identify and disconnect the control links (C) from the two section loader control valve (A). 7. Remove the bolts (D). 8. Retain the bolts (D) for reuse. 9. Remove the two section loader control valve (A) from the machine.
10. Remove the tie rods (E1) and the nuts (E2) which secure the two section loader control valve (A). 11. Remove the cover plate (F). 12. Retain the cover plate (F) for reuse.
10 EN
