2 - KIT CONTENT
2 - KIT CONTENT Kit overview NOTE: To check the items part numbers of this kit, please refer to the Parts Catalogue. NOTE: The following table shows the items numbered as in the installation instruction. Item 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Description Cable tie Washer 11 X 20 X 2 mm Nut M10 Double loop cable tie 300 – 397 mm Drain hose (loader arm side) Drain hose (rear frame side) 90° bulkhead union elbow 12 mm or 1/2 in Bulkhead locknut 12 mm or 1/2 in ORS/SAE O-ring boss adapter 90° swivel elbow 12 mm or 1/2 in Coated closed clamp 15.9 mm bolt 1/2 Female quick coupling Coated closed clamp 16 mm bolt M8 Washer 9 X 16 X 1.6 mm Bolt M8 X 16
Quantity 5 1 1 2 1 1 1 1 1 1 1 1 1 1 1
