01 SYSTEM HAMMER COMPONENTS (CAB

331/ C 05 p1 2/2019

6 SECTION PILOT CONTROL VALVE SUPPORT, COMPLETE

REF FN PART NUMBER

1 85827476 3 85827475 4 85805318 5 85826100 6 47050686 7 47050653 8 83963371 9 85812173 10 85817226

YR/SN QTY DESCRIPTION

1 FLEXIBLE HOSE 1 FLEXIBLE HOSE 9.5mm ID x 2175mm L 1 ELBOW 9/16" - 18 JIC x 9/16" - 18 ORB 1 REDUCER 1-5/16 Male x 9/16" Female 1 HYD CONNECTOR 9/16-18 JIC x 9/16-18 ORB 1 ELBOW 7/16'-20, Carbon Steel 1 FITTING 11/16"-16 ORFS x 9/16"-18 ORB 1 FLEXIBLE HOSE 6.35mm ID x 1600mm L 1 QUICK MALE COUPLING 11/16" - 16 OD

B95TC-NA BACKHOE LOADER

331/ C 06 p1 2/2019

6 SECTION PILOT CONTROL VALVE SUPPORT, COMPLETE (CENTER PIVOT)

Pilot Control Version
