5 Compressed-air system 1- and 2-line system, 2-line system 2196
Key to diagram Item
Component
1
Compressor
2
Frost protection pump
3
Pressure controller (7.9 ... 8.3 bar)
4
Air container (15 litres)
5
Drain valve
6
Pressure sensor (0 ... 10 bar)
7
Overflow valve (6.7 ... 7 bar)
8
Trailer control valve (1-line system)
9
Trailer control valve (2-line system)
10
4/2-way valve (pilot control)
11
Shuttle valve
12
4/2-way valve (parking brake)
13
Service line hose coupler of 1-line system (black)
14
Accumulator service line hose coupler (red)
15
2-line brake system service line hose coupler (yellow)
16
Non-return valve
a
to display in monitor
B
to auxiliary consumers (if provided)
C
Actuation of brake pedal switch
D
Control of service brake, outputs BR1 or BR2 on main brake valve (VII)
E
Control of parking brake
