Checks/Adjustments Accelerator control adjustment
A
161msm05
Make sure that: 1 - The adjustment measurement (A) satisfies the following 2 conditions: - The pedal shoe effort must be between 3 and 5 daN. - The pedal must return easily to the high position.
A1.12
2 - The angular detector values: - Raised pedal (in idling speed stop): Maximum 0,9 V. - Pedal fully depressed: Minimum 3,1 V.
The voltage will be measured with ignition switched on. Use the cable n° 60 05 005 577 to measure the output voltage.
Ares 806 – 09.2004 – GB
